- 200 Amp Pagoda With Tail Input to LSC19 Receptacles
- 200 Amp 3 Phase Hammerhead to Locking Receptacles
- 200 Amp 3 Phase Pagoda to 50 Amp Locking Receptacles
- 200 Amp 3 Phase Power Station to NEMA TT-30 RV Receptacles, Feed Thru, Weather Resistant
- 200 Amp 3 Phase Motion Picture Box, Feed Thru
- 200 Amp 3 Phase Moving Light Box
- 200 Amp 3 Phase Power Station Jr. to GFCI Duplex Receptacles, Weather Resistant
200 Amp Pagoda With Tail Input to LSC19 Receptacles
- Input: (1) set of (5) 16 Series Cam-type color-coded plugs on ?18 inch #1 AWG type SC tails
- Output: (4) 20 Amps per circuit, 6-circuit, 120 VAC, ?LSC19 female panel mount receptacles
- (3) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC, ?duplex receptacles
- Overcurrent Protection: (27) 20 Amp, Single Pole branch-rated circuit breakers
200 Amp 3 Phase Hammerhead to Locking Receptacles
- Input: (1) set of (5) 16 Series Cam-type color-coded mount inlets
- Output: (10) NEMA L21-20, 20 Amp, 3 Phase, 4 Pole, 5 Wire, 120/208Y VAC locking receptacles
- Feed Thru: None
- Overcurrent Protection: (10) 20 A, 3-Pole branch-rated circuit breakers
200 Amp 3 Phase Pagoda to 50 Amp Locking Receptacles
- Input: (1) set of (5) 16 Series Cam-type color-coded panel mount inlets
- Output: (6) 50 Amp, 3 Pole, 4 Wire, 120/240 VAC, California-style locking receptacles
- Feed Thru: None
- Overcurrent Protection: (6) 50 Amp, 2 Pole branch-rated circuit breakers
200 Amp 3 Phase Power Station to NEMA TT-30 RV Receptacles, Feed Thru, Weather Resistant
- Input: (1) set of (5) 16 Series Cam-type color-coded panel mount inlets
- Output: (21) NEMA TT-30, 30 Amp, 2 Pole, 3 Wire, 125 VAC straight blade RV receptacles
- Feed Thru: (1) set of (5) 16 Series Cam-type color-coded panel mount outlets
- Overcurrent Protection: (21) 30 Amp, Single Pole branch-rated circuit breakers
200 Amp 3 Phase Motion Picture Box, Feed Thru
- Input: (1) set of (5) 16 Series Cam-type color-coded panel mount inlets
- Output: (6) 100 Amp, 2 Pole, 3 Wire, 120 VAC stage pin receptacles (2) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC duplex receptacles
- Feed Thru: (1) set of (5) 16 Series Cam-type color-coded panel mount receptacles
- Overcurrent Protection: (6) 100 Amp, Single Pole branch-rated circuit breakers
200 Amp 3 Phase Moving Light Box
- Input: (1) set of (5) 16 Series Cam-type color-coded panel mount inlets
- Output: (12) NEMA L6-20, 20 Amp, 2 Pole, 3 Wire, 220 VAC, locking receptacle wired in parallel with (2) 20 Amps per circuit, 6-circuit, 220 VAC, LSC19 female panel mount receptacles, (1) NEMA 5-20, 20 Amp, 2 Pole, 3 Wire, 120 VAC, duplex receptacle
- Feed Thru None
- Overcurrent Protection: (12) 20 Amp, 2 Pole branch-rated circuit breakers, (1) 20 Amp, Single Pole branch-rated circuit breaker
200 Amp 3 Phase Power Station Jr. to GFCI Duplex Receptacles, Weather Resistant
- Input: (1) set of (5) 16 Series Cam-type color-coded panel mount inlets
- Output: (24) NEMA 5-20, 20Amp, 2 Pole, 3 Wire, 120 VAC, GFCI duplex receptacles
- Feed Thru: None
- Overcurrent Protection: (24) 20 Amp, Single Pole branch-rated circuit breakers
