Edison
- INPUT: 100 A 120 V BATES 50/60 Hz / CAM LOCK AVAILABLE
- OUTPUT: EDISON 12x1.2 kW or 6x2.4kW output channels
- CONTROL:
- All features configurable via User Interface Display Screen or web GUI.
- 4 way rotary switch can quickly change modes for channels globally or individually.
- FEATURES:
- Ethernet enabled, compatible with Art-Net or sACN 9 Port Integrated GIGABIT Ethernet Switch.
- Ethernet Status & SPEED LED indicators per ETHERNET port.
- 8 Universe DMX Node, with 8 individually configurable XLR output ports with separate universes and capability.
- 12 XLR Ports in all plus DMX pass through.
- 2 universes of CRMX wireless, TX or RX.
- Self-terminating DMX with Status Quo FOR ALL XLR OUTPUTS
- Ghost Load Featured for problematic fixtures such as dimmable leds and low wattage incandescents selectable.
Socapex
- INPUT: 100 A 120 V BATES 50/60 Hz / CAM LOCK AVAILABLE
- OUTPUT: Socapex 12x1.2 kW or 6x2.4kW output channels
- CONTROL:
- All features configurable via User Interface Display Screen or web GUI.
- 4 way rotary switch can quickly change modes for channels globally or individually.
- FEATURES:
- Ethernet enabled, compatible with Art-Net or sACN 10 Port Integrated GIGABIT Ethernet Switch (8 on front 2 in the back).
- Ethernet Status & SPEED LED indicators per ETHERNET port.
- 8 Universe DMX Node, with 8 individually configurable XLR output ports with separate universes and capability.
- 12 XLR Ports in all plus DMX pass through
- 2 universes of CRMX wireless, TX or RX.
- Self-terminating DMX with Status Quo FOR ALL XLR OUTPUTS
- Ghost Load Featured for problematic fixtures such as dimmable leds and low wattage incandescents selectable.
Data Sphere
- INPUT: 20 AMP POWERCON 20A BREAKER PROTECTION POWERCONN/EDISON ADAPTER PROVIDED.
- CONTROL:
- All features configurable via User Interface Display Screen or web GUI.
- Copy of DMX universe from one XLR port to another.
- FEATURES:
- Ethernet enabled, compatible with Art-Net or sACN 9 Port Integrated GIGABIT Ethernet Switch.
- Ethernet Status & SPEED LED indicators per ETHERNET port.
- 8 Universe DMX Node, with 8 individually configurable XLR output ports with separate universes and capability.
- 2 Optically isoleted 4 port DMX splitters. DMX Universe for both are determined by the node port A or E.
- 2 universes of CRMX wireless, TX or RX.
- Self-terminating DMX with Status Quo FOR ALL XLR OUTPUTS.
